$MC_TRAFO_AXES_IN_1[4] = 0
$MA_ROT_IS_MODULO[AX6] = TRUE;
$MC_TRAFO_GEOAX_ASSIGN_TAB_1[0] = 1
$MC_TRAFO_GEOAX_ASSIGN_TAB_1[1] = 6
$MC_TRAFO_GEOAX_ASSIGN_TAB_1[2] = 3
$MC_TRANSMIT_BASE_TOOL_1[0] = 0.0
$MC_TRANSMIT_BASE_TOOL_1[1] = 0.0
$MC_TRANSMIT_BASE_TOOL_1[2] = 0.0
$MC_TRANSMIT_ROT_AX_OFFSET_1 = 0.0
$MC_TRANSMIT_ROT_SIGN_IS_PLUS_1 = TRUE
$MC_TRANSMIT_ROT_AX_FRAME_1 = 1
; TRANSMIT ist 2. Trafo
$MC_TRAFO_TYPE_2 = 256
$MC_TRAFO_AXES_IN_2[0] = 1
$MC_TRAFO_AXES_IN_2[1] = 6
$MC_TRAFO_AXES_IN_2[2] = 2
$MC_TRAFO_AXES_IN_2[3] = 0
$MC_TRAFO_AXES_IN_2[4] = 0
$MC_TRAFO_GEOAX_ASSIGN_TAB_2[0] = 1
$MC_TRAFO_GEOAX_ASSIGN_TAB_2[1] = 6
$MC_TRAFO_GEOAX_ASSIGN_TAB_2[2] = 2
$MC_TRANSMIT_BASE_TOOL_2[0] = 4.0
$MC_TRANSMIT_BASE_TOOL_2[1] = 0.0
$MC_TRANSMIT_BASE_TOOL_2[2] = 0.0
$MC_TRANSMIT_ROT_AX_OFFSET_2 = 19.0
$MC_TRANSMIT_ROT_SIGN_IS_PLUS_2 = TRUE
$MC_TRANSMIT_ROT_AX_FRAME_2 = 1
