PLC-Grundprogramm (P3)
13.13 Bausteinbeschreibungen
Deklaration der Funktion
FUNCTION_BLOCK FB 10
VAR_INPUT
END_VAR
VAR_OUTPUT
END_VAR
VAR_INOUT
END_VAR
1036
In1 : BOOL := TRUE;
In2 : BOOL := TRUE;
In3 : BOOL := TRUE;
Quit1: : BOOL;
Quit2: :BOOL;
TimeValue1: TIME := T#0ms;
TimeValue2: TIME := T#0ms;
TimeValue3: TIME := T#0ms;
Out0 : BOOL;
Out1 : BOOL;
Out2 : BOOL;
Out3 : BOOL;
FirstRun : BOOL;
//Input 1
//Input 2
//Input 3
//Quit 1 Signal
//Quit 2 Signal
//TimeValue for Output 1
//TimeValue for Output 2
//TimeValue for Output 3
//Output without Delay
//Delayed Output to False by Timer 1
//Delayed Output to False by Timer 2
//Delayed Output to False by Timer 3
//TRUE by User after 1. Start of SPL
