Brief instruction 808D Milling
Basic Theory
Frequently used letter meanings of typical fixed cycle codes in ISO mode.
P. Descriptions
X/Y Cutting end point X/Z absolute
coordinate values
The distance incremental value
between R point and the bottom of the
Z
hole, or the absolute coordinate value
of the bottom of the hole
The distance incremental value
between the start point plane and R
R
point or the absolute coordinate value
of R point
The depth of every cut
Q （incremental value）
Offset value
（incremental value）
P The delay time at the bottom of the
hole
F The feedrate of the cutting
K The repeat times of the fixed cycle
In 808D, the default ISO program feed distance unit is mm!
(X100→100mm)
Note: change the parameter 10884 = 0, to make X100
808D
ISO Mode
Unit Applied range and note
G73 / G74 / G76 G81 ~
G87 / G89
G73 / G74 / G76 G81 ~
G87 / G89
G73 / G74 / G76 G81 ~
G87 / G89
G73 / G83
G76 / G87
ms G74 / G76 / G89 G81 ~
G87
mm/min G73 / G74 / G76 G81 ~
G87 / G89
G73 / G74 / G76 G81 ~
G87 / G89
→ →
100 um / X100. 100 mm
Brief introduction of typical fixed cycle codes in ISO mode.
For the meaning of letters when programming typical fixed cycles,
please refer the figure on the left!
G73 fast-speed deep hole drilling
Common programming structures:
G73 X—Y—Z—R—Q—F—K
Motion process:
①
Drilling motion (-Z) → intermediate
feed
②
Motion at the bottom of the hole →
none
③
Retraction motion (+Z) → fast feed
G74 reverse tapping cycle
Common programming structures:
G74 X—Y—Z—R—P—F—K
Motion process:
①
Drilling motion(-Z) → cutting feed
②
Motion at the bottom of the hole →
spindle rotation in positive direction
③
Retraction motion(+Z) → cutting feed
Page 384
OPTIMUM
M A S C H I N E N - G E R M A N Y
G73 application example program:
M3 S1500 ;spindle rotation
G90 G99 G73 X0 Y0 Z-15 R-10 Q5 F120
;after orientation drill 1st hole, back to R point
Y-50 ;after orientation drill 2nd hole, back to R point
Y-80 ;after orientation drill 3rd hole, back to R point
X10 ;after orientation drill 4th hole, back to R point
Y10 ;after orientation drill 5th hole, back to R point
G98 Y75 ;after orientation drill 6th hole, back to R point
G80 ;cancel fixed cycle
G28 G91 X0 Y0 Z0 ;back to reference point
M5 ;spindle rotation stop
M30
G74 application example program:
M4 S100 ;spindle rotation
G90 G99
G74 X300 Y-250 Z-150 R-120 P300 F120
;after orientation drill 1st hole, back to R point
Y-550 ;after orientation drill 2nd hole, back to R point
Y-750 ;after orientation drill 3rd hole, back to R point
X1000 ;after orientation drill 4th hole, back to R point Y-
550 ;after orientation drill 5th hole, back to R point G98
Y750 ;after orientation drill 6th hole, back to R point G80
;cancel fixed cycle
G28 G91 X0 Y0 Z0 ;back to reference point
M5 ;spindle rotation stop
M30
