Brief instruction 808D Milling
SEQUENCE
"USB" is used to transfer the programs to and from the NC.
Use the "Copy" and "Paste" SKs to transfer the part program from NC to
Step 4
USB.
Connect a USB device with sufficient memory to the USB interface on the PPU.
Press the "NC" SK on the PPU.
Use "Cursor + Select" to select the required part program.
The selected program will be highlighted.
Press the "Copy" SK on the PPU.
Press the "USB" SK on the PPU.
Press the "Paste" SK on the PPU.
Use the "Copy" and "Paste" SKs to transfer the part program from NC to
Step 5
USB.
Connect the USB device with the stored target programs to the USB interface on the
PPU.
Press the "USB" SK on the PPU.
Use "Cursor + Select" to select the required part
The selected program will be highlighted.
Press the "Copy" SK on the PPU.
Press the "NC" SK on the PPU.
Press the "Paste" SK on the PPU.
808D
Additional Information Part 1
+
program.
+
Page 355
SEQUENCE
A shared network drive can be made using an ethernet
Shared Network
connection between the PC and the PPU so the transferring and
Drive (only
backup of NC programs can be performed easier.
ADVANCED)
Set PPU IP address.
Step 1
Connect PC using a network cable to the rear X130 ethernet port on the PPU
Press key:
+
Press "Serv. Displ." SK
Press "Serv. Displ." SK
Press "Network Info" button to enter the "Local
Operating and Programming — Milling
OPTIMUM
M A S C H I N E N - G E R M A N Y
Press key:
Configuration Data"
