Brief instruction 808D Milling
SEQUENCE
Program
skip
Method 1
";" code
Using ";" code at the
beginning of the
block can skip this
string.
";" can also be used
to add remarks to
the block.
See the figure on the
right for an example
of use.
Using ";" code at the beginning
of the program block N95, this
string will be skipped without
execution.
808D
Additional Information Part 2
N5 G17 G90 G500 G71
N10 T1 D1 M6
N15 S5000 M3 G94 F300
N20 G00 X50 Y50 Z5
N25 G01 Z-20
N30 Z5
...
N85 T2 D1 M6 ; Tool change
N90 S5000 M3 G94 F300
; N95 G00 X60 Y55 Z10
Using ";" code to add a
remark to the N85 function,
without any influence on the
execution.
Method 2
Press the "Machine" key on the PPU.
Press the "Auto" key on the MCP.
Press the "Prog cont." SK on the PPU.
Press the "Prog cont." SK on the PPU.
When "SKP" is displayed (red circle), the skip function has been activated.
After activating "SKP", using "/" at the beginning of the program string (shown in
purple circle), the string will be skipped without influencing the execution.
