7.2 G functions to PAL
G0 Travelling in rapid traverse
G1 Linear interpolation during process
G2 Circular interpolation clockwise
G3 Circular interpolation anti-clockwise
G4 Retention period
G9 Accurate stop
G10 Travelling in rapid feed in polar coordi-
nates
G11 Linear interpolation with polar coordinates
G12 Circular interpolation clockwise with polar
coordinates
G13 Circular interpolation anti-clockwise with
polar coordinates
G45 Linear tangential travelling on a contour
G46 Linear tangential travelling off the contour
G64 Accurate stop off
