Brief instruction 808D Milling
Basic Theory
Edit
program
The program shown in the editor can be created
and edited with the appropriate keys.
Mill.
Edit Cont. Drill.
808D
Create Part Program Part 1
Execute
Renumber
Search
Mark
On
Copy
Paste
Re-
Sin.
Activate
comp.
Inches and
mm
G71
With G71 at the header,
the geometry data will be
in the metric unit system,
the feedrate in the default
metric system.
G70
With G70 at the header,
the geometry data will be
in the imperial (inches)
unit system, the feedrate
in the default metric
system.
Page 325
OPTIMUM
M A S C H I N E N - G E R M A N Y
Header N5 G17 G90 G54
T, F, S function
N10 T1 D1 M6
N15 S5000 M3 G94 F300
N20 G00
Geometry data / motion
N25 G01
N30 Z5
N35 G00
Return to change tool
N5 G17 G90 G54
Header
N10 T1 D1 M6
T, F, S function
N15 S5000 M3 G94 F300
N20 G00
Geometry data / motion
N25 G01
N30 Z0.196
Return to change tool
N35 G00
Operating and Programming — Milling
G71
X100 Y100 Z5
Z-5
Z500 D0
G70
X3.93 Y3.93 Z5
Z-0.787
Z19.68 D0
