2.5 Dimensions
Height [mm]
Depth [mm]
Width [mm]
Total weight [kg]
2.6 Working area, traverse path
X-axis [mm]
Y-axis [mm]
Z axis travel [mm]
Z axis
Distance spindle - milling table [mm]
2.7 Accuracy
Repeat accuracy
Positioning accuracy
2.8 Torques of servo motors
X axis
Y axis
Z axis
2.9 Milling table
Table length [mm]
Table width [mm]
T - slot size / number / distance [mm]
Max. load [kg]
max. feedrate [mm/min.]
2.10 Tool changer
Max. number of tool places
max. tooling diameter [mm]
Max. tool lenght [mm]
Max. tool weight [kg]
Tool change time [s]
2.11 Environmental conditions - operation
Temperature
Technical specification
Version 1.1.2 dated 2019-05-07
F80 (Advanced)
3.4 "Installation plan F80" on
page 232
1900
400
225
375
75 to 475
± 0.015mm
± 0.015mm
5 Nm
( 3.5 Nm )
5 Nm
( 6 Nm )
6 Nm
( 6 Nm )
800
260
16 / 5 / 50
150
10000
10
60
200
6
7
19 - 21 °C (for an optimum milling result)
19 - 21 °C (for operation without malfunctions)
Translation of the original instructions
OPTIMUM
M A S C H I N E N - G E R M A N Y
F105 (Advanced)
3.5 "Installation plan F105"
on page 234
2800
550
305
460
100 to 600
± 0.01mm
± 0.01mm
8 Nm
8 Nm
11 Nm
800
320
14 / 3 /100
300
10000
12
70
300
6
7
