2.18 Optional fourth axis
Table diameter [ mm ]
Weight [ kg ]
Center height table in vertical [ mm ]
Table height in horizontal [mm]
Thru-hole diameter [mm]
Diameter centering shoulder [mm]
Width of T-slot
Width of sliding block
Type servomotor
Transmission ratio
Min. increment [ degree ]
max. speed [ 1/min ]
pneumatic clamping force at 5 bar operating pres-
Indexing accuracy (sec.)
unidirectional repeatability (sec.)
max. perm. machining torque
max. weight workpiece horizontal
max. weight workpiece vertical
GB CNC 120-R
Page 228
®
only F105 808D Advanced
-
sure
Translation of the original instructions
120
38
110
150
25
H7
40
H7
12
H7
14
Siemens 1FK7042
1:60
0.001°
-1
44.4 with motor 4000 min
118 Nm
60´´
+/- 2´´
118 Nm
W = 100 kg
W = 50 kg
