Brief instruction 808D Milling
SEQUENCE
Step 2
The range of tool numbers which can be created
by this system is 1 ~32000.
The machine can be loaded with a maximum of
64 tools / 128 tool edges.
Press the "New tool" SK on the PPU.
Select the type of tool required.
Enter "1" at "Tool No."
Tool list
New milling tool
Tool No.:
Identifier
milling tool
Press the "OK" SK on the PPU.
Enter the "Radius" of the milling tool.
Press the "Input" button on the PPU.
808D

Tool Setup

Create
tool edge
Use "D" code to specify the tool edge. The system activates tool edge
Step 1
no. 1 per default at the start.
Press the "Offset" key on the PPU.
New
tool
Press the "Tool list" SK on the PPU.
Milling
tool
Use direction keys to select the tool which
Drilling
tool
Tapping
tool
Ball end Tool list
mil. tool
Type
Lenght1
Tool Tool
list wear
Press the "Edges" SK on the PPU.
Press the "New edge" SK on the PPU.
Page 311
OPTIMUM
M A S C H I N E N - G E R M A N Y
A tool must have been created and selected
before creating a tool edge!
needs to add a tool edge.
Geometry
Radius
Work
R
offset
var.
Operating and Programming — Milling
Tool
list
Or
New
edge
Reset
edge
Delete
edge
Back
User
Set
data data
Edges
New
edge
