Brief instruction 808D Milling
SEQUENCE
Test tool
The tool setup and workpiece setup must have
offset results
been performed correctly so that it can be
tested as follows!
In order to ensure the machine safety and correctness, the results of the tool offset
should be tested appropriately.
Press the "Machine" key on the PPU
Press the "MDA" key on the MCP.
Press the "Delete file" SK on the PPU.
Enter the test program recommended on the right.
(can also be customized)
Press the "ROV" key to ensure the "ROV" function
Note: The ROV function activates the feedrate override switch under the G00 function.
Make sure the feedrate override on the MCP is at 0%!
Press "CYCLE START" on the MCP.
Increase the feedrate override gradually to avoid accidents caused by an axis moving
too fast. Observe whether the axis moves to the set position.
808D
Delete
file
G54 (select offset
panel as required)
T1 D1
G00 X0 Y0 Z5
is active (lit up).
Workpiece Setup
Page 322
