5.2.1 Key combination
Excerpt from the manual of the operating instructions for "SINUMERIK 808D OPM Opera-
tion"
Element
<ALT> + <X>
<ALT> + <V>
<ALT> + <C>
<ALT> + <B>
<ALT> + <M>
<ALT> + <N>
<SHIFT> +
<ALT> + <H>
<ALT> + <L>
<ALT> + <S>
<=>
<CTRL> + <B>
<CTRL> + <C>
<CTRL> + <D>
<CTRL> + <P>
<CTRL> + <R>
<CTRL> + <S>
GB F80 | F105
Page 256
®
Opens the "Machine" operating area
Opens the "Program" operating area
Opens the "Offset" operating area
Opens the "Program" operating area
Opens the "Alarm" operating area
Opens the "System" operating area
Calls the online help system.
Enables input of lowercase letters.
Applicable only when the user interface language is Chinese.
Calls the input method editor for entering Chinese characters.
Calls the pocket calculator. Note that this function is not applicable in
MDA mode.
Selects text in program blocks.
Copies the selected text.
Shows pre-defined slides on the screen.
Captures screens
Restarts the HMI
Saves start-up archives
