8 Notes, messages and error messages
All messages and alarms are displayed in plain text on the control panel. The alarm text con-
tains the date, time and a suitable symbol for the cancel criterion.
Alarms and messages are displayed separately according to the following criteria:
Alarms and messages in the part program.

Alarms and messages from the PLC and alarms and messages that concern the machine.

The description of the alarms and messages in the part program and other alarms and mes-
sages from the PLC are in the Siemens manual.
Number
700000
700001
700002
700003
700004
700005
700006
700007
700008
700009
700010
700011
700012
700013
700014
700015
700016
700017 Operation chuck when sp. or part prog. is running
700018
700019
700020
700021 LUBRICANT LIQUID POSITION IN LOW LEVEL
700022
700023 PROGRAMMED TOOL NUM. > MAX. TURRET NUMBER
700024
700025
700026
700027 APPROACH REF.POINT AGAIN AFTER ROT. MONITORING
700028
700029
700030
700031
700032
700033 Magazine turn key when magazine or sp. not ready
Notes, messages and error messages
Version 1.1.2 dated 2019-05-07
Message
User alarm 01
The manual mode of MGZ is active
Air pressure is not enough (bigger 0.6 Mpa)
The door is open
User alarm 04
Main power three phase direction error
User alarm 07
User alarm 08
User alarm 09
User alarm 10
HHU is active
Not able to lock tool in expected time
Spindle in braking progress
Operation while chuck is not closed
Gear-change time out
Gear level position error
DRIVES NOT READY
COOLING MOTOR OVERLOAD
COOLANT LIQUID POSITION IN LOW LEVEL
LUBRICATING MOTOR OVERLOAD
TURRET MOTOR OVERLOAD
Max. tool number setting error
NO POSITION SIGNALS FROM TURRET
Not able to find expected tool in monitor time
Tool is not locked
Reminding information for 1st service plan
Alarm for 1st service plan
Magazin not in spindle pos. or original pos.
Magazin in spindle pos. and original pos.
