Brief instruction 808D Milling
SEQUENCE
The following sequence should be followed to create a part
Create
program:
program
Step 1
Programs can be created
with the "program
manager".
You can select the
"program manager" using
the key located on the
PPU.
Step 2
Select NC as the storage location for the
program. Programs can only be created in
the NC.
Step 3
Create a new program with the "New" SK on the right of the PPU.
Name
Type
808D
Create Part Program Part 1
Length Date Time
Execute
New
Step 4
You can choose Name
"New" or "New
directory".
Choose "New" to
create a program.
Choose "New
directory" to create
a file.
Step 5
Now the program
is opened and can
be edited.
The system will save it automatically after editing.
End
Page 324
OPTIMUM
M A S C H I N E N - G E R M A N Y
1
Type Lenght Date
New G code program
Type:
Name:
2
key to open file, [DEL]
key to delete file
Operating and Programming — Milling
Time New
file
New
directory
Cancel
OK
