Brief instruction 808D Milling
Additional Information Part 1
Description
This unit describes how to perform simple tasks on the machine and provides some
additional information which may be required to operate the machine correctly.
Content
RS232 + USB
Shared Network
Drive (only
ADVANCED)
Help
Manual face
cutting
808D
Additional Information Part 1
R
parameters
Time
change
Save
data
Gear
change
End
SEQUENCE
RS232 + USB
It is recommended to use the "SINUCOM PCIN" communication SW
Step 1
provided by Siemens to transfer the standard program.
Adjust the parameter settings on the PPU to match the settings of the communication
SW on the PC.
Press "Program Manager" on the PPU.
Press the "RS232" SK on the PPU.
Press the "Settings" SK on the PPU.
Adjust the parameters in "Communication settings" to match the settings of
communication SW on PC.
Press the "Save" SK on the PPU.
Press the "Back" SK on the PPU.
Page 353
OPTIMUM
M A S C H I N E N - G E R M A N Y
RS232 is used to transfer the programs to and from
the NC.
Operating and Programming — Milling
