Brief instruction 808D Milling
A shared network drive can be made using an ethernet
connection between the PC and the PPU so the transferring and
Help
backup of NC programs can be performed easier.
The PPU has an online help which shows the contents of standard documents.
Press the "Help" key on the PPU.
Press the "Help" key on the PPU.
The help information related to the current topic will be shown on screen.
Press the "OEM Manual" SK on the PPU.
The online help manual of the OEM will be shown on the screen.
Press the "TOC" SK on the PPU.
The online help from the Siemens manual will be shown.
808D
Additional Information Part 1
Manual face
"Face cutting" is used to cut the oversized materials on the rough face before starting
to machine.
Step 1
Enter appropriate values in "Retraction plane" and "Safety distance".
Press the "Input" key on the PPU to activate the settings.
Page 359
cutting
Press the "Machine" key on the PPU.
Press the "JOG" key on the MCP.
Press the "Sett." SK on the PPU.
Operating and Programming — Milling
