Blackmagic Design Videohub Master Control Pro Installations- Und Bedienungsanleitung Seite 42

Enter a GPI and Tally Name and the IP address of the Videohub you
want to connect to
Updating the Software in your Videohub Controller
Follow these steps to check if your Videohub control panel's internal software is up to date:
1 Connect your Videohub control panel to the computer via USB.
2 Launch Blackmagic Videohub Hardware Panel Setup.
3 If a software update is required, a message will appear asking if you would like to update
your Videohub control panel. Click Yes. The update will take about 2 minutes to complete.
4
The message "Software Update Complete" should appear at completion of the update.
Click OK to dismiss the message. Settings can be changed now if desired and this is a
good opportunity to give each Videohub control panel a unique name.
5 You can now unplug the USB cable from your Videohub control panel.
This message will appear if an internal software update
is required
Setting up your Videohub Controller
Blackmagic Videohub Setup is an administration utility used to configure your Videohub,
customize your input and output labels, name your Videohub, and adjust the network settings
and more.
NOTE
After installing the Blackmagic Videohub software, the Videohub server is also
automatically installed.
Videohub Hardware Panel Setup 42
