13 Anhang
Auswahllisten für Signalverknüpfungen
Liste der Winkel−Signalquellen
13.2.3 Liste der Winkel−Signalquellen
Symbol in Signalflussplänen: E
Auswahl−Nr. Signal
10 AIF1In−W2/W3
11 AIF2In−W0/W1
12 AIF3In−W0/W1
13 CAN1In−W2/W3
14 CAN2In−W0/W1
15 CAN3In−W0/W1
16 FCODE−C0474/1
17 FCODE−C0474/2
18 FCODE−C0474/3
19 FCODE−C0474/4
20 FCODE−C0474/5
21 AIF1In−W0/W1
22 AIF2In−W2/W3
23 AIF3In−W2/W3
24 CAN1In−W0/W1
25 CAN2In−W2/W3
26 CAN3In−W2/W3
30 SPEED−MCTRL.Pos
40 TORQUE−MCTRL.Pos
651 InNeg−PhiOut1
652 InNeg−PhiOut2
671 OutNeg−PhiOut1
672 OutNeg−PhiOut2
448
Anzeige Keypad Variable für Global Drive Oscilloscope (GDO)
AIF1−W2/W3 AIF1_dnInD1_p
AIF2−W0/W1 AIF2_dnInD1_p
AIF3−W0/W1 AIF3_dnInD1_p
CAN1−W2/W3 CAN1_dnInD1_p
CAN2−W0/W1 CAN2_dnInD1_p
CAN3−W0/W1 CAN3_dnInD1_p
FCE−474_1 FCODE_dnC474_1_p
FC−474_2 FCODE_dnC474_2_p
FC−474_3 FCODE_dnC474_3_p
FC−474_4 FCODE_dnC474_4_p
FC−474_5 FCODE_dnC474_5_p
AIF1−W0/W1 AIF1_dnInD0_p
AIF2−W2/W3 AIF2_dnInD2_p
AIF3−W2/W3 AIF3_dnInD2_p
CAN1−W0/W1 CAN1_dnInD0_p
CAN2−W2/W3 CAN2_dnInD2_p
CAN3−W2/W3 CAN3_dnInD2_p
SP−M.Pos MCTRL_dnPos_p
T−M.Pos MCTRL_dnPos_p
IN−PhiO1 InNeg_dnPhiOut1
IN−PhiO2 InNeg_dnPhiOut2
ON−PhiO1 OutNeg_dnPhiOut1
ON−PhiO2 OutNeg_dnPhiOut2
l
EDBCSXS064 DE 4.0
