13 Anhang
Auswahllisten für Signalverknüpfungen
Liste der digitalen Signalquellen
Auswahl−Nr. Signal
99 AIF3In−Bit0
100 AIF3In−Bit1
101 AIF3In−Bit2
102 AIF3In−Bit3
103 AIF3In−Bit4
104 AIF3In−Bit5
105 AIF3In−Bit6
106 AIF3In−Bit7
107 AIF3In−Bit8
108 AIF3In−Bit9
109 AIF3In−Bit10
110 AIF3In−Bit11
111 AIF3In−Bit12
112 AIF3In−Bit13
113 AIF3In−Bit14
114 AIF3In−Bit15
115 AIF3In−Bit16
116 AIF3In−Bit17
117 AIF3In−Bit18
118 AIF3In−Bit19
119 AIF3In−Bit20
120 AIF3In−Bit21
121 AIF3In−Bit22
122 AIF3In−Bit23
123 AIF3In−Bit24
124 AIF3In−Bit25
125 AIF3In−Bit26
126 AIF3In−Bit27
127 AIF3In−Bit28
128 AIF3In−Bit29
129 AIF3In−Bit30
130 AIF3In−Bit31
131 DigIn−CInh
132 DigIn−In1
133 DigIn−In2
134 DigIn−In3
135 DigIn−In4
136 DigIn−safe_standstill
137 CAN−Ce1CommErrCanIn1
138 CAN−Ce2CommErrCanIn2
139 CAN−Ce3CommErrCanIn3
140 CAN−Ce4BusOffState
141 CAN1In−Ctrl.Quickstop_B3
142 CAN1In−Ctrl.Disable_B8
143 CAN1In−Ctrl.CInhibit_B9
144 CAN1In−Ctrl.TripSet_B10
145 CAN1In−Ctrl.TripReset_B11
146 CAN1In−Ctrl.Bit0
438
Anzeige Keypad Variable für Global Drive Oscilloscope (GDO)
AIF3−Bit0 AIF3_bInB0_b
AIF3−Bit1 AIF3_bInB1_b
AIF3−Bit2 AIF3_bInB2_b
AIF3−Bit3 AIF3_bInB3_b
AIF3−Bit4 AIF3_bInB4_b
AIF3−Bit5 AIF3_bInB5_b
AIF3−Bit6 AIF3_bInB6_b
AIF3−Bit7 AIF3_bInB7_b
AIF3−Bit8 AIF3_bInB8_b
AIF3−Bit9 AIF3_bInB9_b
AIF3−Bit10 AIF3_bInB10_b
AIF3−Bit11 AIF3_bInB11_b
AIF3−Bit12 AIF3_bInB12_b
AIF3−Bit13 AIF3_bInB13_b
AIF3−Bit14 AIF3_bInB14_b
AIF3−Bit15 AIF3_bInB15_b
AIF3−Bit16 AIF3_bInB16_b
AIF3−Bit17 AIF3_bInB17_b
AIF3−Bit18 AIF3_bInB18_b
AIF3−Bit19 AIF3_bInB19_b
AIF3−Bit20 AIF3_bInB20_b
AIF3−Bit21 AIF3_bInB21_b
AIF3−Bit22 AIF3_bInB22_b
AIF3−Bit23 AIF3_bInB23_b
AIF3−Bit24 AIF3_bInB24_b
AIF3−Bit25 AIF3_bInB25_b
AIF3−Bit26 AIF3_bInB26_b
AIF3−Bit27 AIF3_bInB27_b
AIF3−Bit28 AIF3_bInB28_b
AIF3−Bit29 AIF3_bInB29_b
AIF3−Bit30 AIF3_bInB30_b
AIF3−Bit31 AIF3_bInB31_b
DIG−CInh DIGIN_bCInh_b
DIG−In1 DIGIN_bIn1_b
DIG−In2 DIGIN_bIn2_b
DIG−In3 DIGIN_bIn3_b
DIG−In4 DIGIN_bIn4_b
DIG−SS DIGIN_b_safe_standstill_b
CAN−Ce1 CAN_bCe1CommErrCanIn1_b
CAN−Ce2 CAN_bCe2CommErrCanIn2_b
CAN−Ce3 CAN_bCe3CommErrCanIn3_b
CAN−Ce4 CAN_bCe4BusOffState_b
CAN1−CB3 CAN1_bCtrlQuickstop_b
CAN1−CB8 CAN1_bCtrlDisable_b
CAN1−CB9 CAN1_bCtrlCInhibit_b
CAN1−CB10 CAN1_bCtrlTripSet_b
CAN1−CB11 CAN1_bCtrlTripReset_b
CAN1−CB0 CAN1_bCtrlB0_b
