13 Anhang
Auswahllisten für Signalverknüpfungen
Liste der digitalen Signalquellen
Auswahl−Nr. Signal
713 AIF1In−W1.Bit13
714 AIF1In−W1.Bit14
715 AIF1In−W1.Bit15
800 CAN1In−W1.Bit0
801 CAN1In−W1.Bit1
802 CAN1In−W1.Bit2
803 CAN1In−W1.Bit3
804 CAN1In−W1.Bit4
805 CAN1In−W1.Bit5
806 CAN1In−W1.Bit6
807 CAN1In−W1.Bit7
808 CAN1In−W1.Bit8
809 CAN1In−W1.Bit9
810 CAN1In−W1.Bit10
811 CAN1In−W1.Bit11
812 CAN1In−W1.Bit12
813 CAN1In−W1.Bit13
814 CAN1In−W1.Bit14
815 CAN1In−W1.Bit15
880 SYS−Clock01Hz
881 SYS−Clock1Hz
882 SYS−Clock10Hz
883 SYS−Clock100Hz
920 AIn1−Error
1000 FIXED 0/FALSE
444
Anzeige Keypad Variable für Global Drive Oscilloscope (GDO)
AIF1−1.13 AIF1_bInWord1B13_b
AIF1−1.14 AIF1_bInWord1B14_b
AIF1−1.15 AIF1_bInWord1B15_b
CAN1−1.0 CAN1_bInWord1B0_b
CAN1−1.1 CAN1_bInWord1B1_b
CAN1−1.2 CAN1_bInWord1B2_b
CAN1−1.3 CAN1_bInWord1B3_b
CAN1−1.4 CAN1_bInWord1B4_b
CAN1−1.5 CAN1_bInWord1B5_b
CAN1−1.6 CAN1_bInWord1B6_b
CAN1−1.7 CAN1_bInWord1B7_b
CAN1−1.8 CAN1_bInWord1B8_b
CAN1−1.9 CAN1_bInWord1B9_b
CAN1−1.10 CAN1_bInWord1B10_b
CAN1−1.11 CAN1_bInWord1B11_b
CAN1−1.12 CAN1_bInWord1B12_b
CAN1−1.13 CAN1_bInWord1B13_b
CAN1−1.14 CAN1_bInWord1B14_b
CAN1−1.15 CAN1_bInWord1B15_b
SYS−0.1Hz SYSTEM_bClock01Hz
SYS−1Hz SYSTEM_bClock1Hz
SYS−10Hz SYSTEM_bClock10Hz
SYS−100Hz SYSTEM_bClock100Hz
AIN1−Err AIN1_bError_b
0/FALSE gC_bFalse
l
EDBCSXS064 DE 4.0
