Lenze ECSES Serie Betriebsanleitung Seite 443

Auswahl−Nr. Signal
344 TORQUE−MCTRL.UnderVoltage
345 TORQUE−MCTRL.OverVoltage
346 TORQUE−MCTRL.ShortCircuit
347 TORQUE−MCTRL.EarthFault
348 TORQUE−MCTRL.NmaxFault
349 TORQUE−MCTRL.ResolverFault
350 TORQUE−MCTRL.MotorTempGreaterSetValue T−M.MoVa
351 TORQUE−MCTRL.MotorTempGreaterC0121
353 TORQUE−MCTRL.KuehlGreaterSetValue
354 TORQUE−MCTRL.KuehlGreaterC0122
355 TORQUE−MCTRL.SensorFault
356 TORQUE−MCTRL.EncoderFault
357 TORQUE−MCTRL.IxtOverload
400 SPEED−NSET.RfgIEqO
401 TORQUE−NSET.RfgIEqO
410 SPEED−BRK.SetQSP
411 SPEED−BRK.NegOut
412 SPEED−BRK.Out
413 SPEED−BRK.SetCInh
414 SPEED−BRK.MStore
420 TORQUE−BRK.SetQSP
421 TORQUE−BRK.NegOut
422 TORQUE−BRK.Out
423 TORQUE−BRK.SetCInh
424 TORQUE−BRK.MStore
450 SPEED−RLQ.QSP
451 SPEED−RLQ.CwCCw
460 TORQUE−RLQ.QSP
461 TORQUE−RLQ.CwCCw
651 InNeg−DigOut1
652 InNeg−DigOut2
653 InNeg−DigOut3
671 OutNeg−DigOut1
672 OutNeg−DigOut2
673 OutNeg−DigOut3
700 AIF1In−W1.Bit0
701 AIF1In−W1.Bit1
702 AIF1In−W1.Bit2
703 AIF1In−W1.Bit3
704 AIF1In−W1.Bit4
705 AIF1In−W1.Bit5
706 AIF1In−W1.Bit6
707 AIF1In−W1.Bit7
708 AIF1In−W1.Bit8
709 AIF1In−W1.Bit9
710 AIF1In−W1.Bit10
711 AIF1In−W1.Bit11
712 AIF1In−W1.Bit12
EDBCSXS064 DE 4.0
Auswahllisten für Signalverknüpfungen
Liste der digitalen Signalquellen
Anzeige Keypad Variable für Global Drive Oscilloscope (GDO)
T−M.UnV MCTRL_bUnderVoltage_b
T−M.OvV MCTRL_bOverVoltage_b
T−M.ShC MCTRL_bShortCircuit_b
T−M.EaF MCTRL_bEarthFault_b
T−M.NmaF MCTRL_bNmaxFault_b
T−M.ResF MCTRL_bResolverFault_b
MCTRL_bMotorTempGreaterSetValue_b
T−M.M121 MCTRL_bMotorTempGreaterC0121_b
T−M.KuVa MCTRL_bKuehlGreaterSetValue_b
T−M.K122 MCTRL_bKuehlGreaterC0122_b
T−M.SenF MCTRL_bSensorFault_b
T−M.EncF MCTRL_bEncoderFault_b
T−M.Ixt MCTRL_bIxtOverload_b
SP−N.REqO ECS_MAIN.L_NSET1.bRfgIEqO_b
T−N.REqO ECS_MAIN.L_NSET1.bRfgIEqO_b
SP−B.QSP ECS_MAIN.L_BRK1.bQSP_b
SP−B.NOut ECS_MAIN.BRK_bNegOut_b
SP−B.Out ECS_MAIN.L_BRK1.bOut_b
SP−B.CInh ECS_MAIN.L_BRK1.bCInh_b
SP−B.MSt ECS_MAIN.L_BRK1.bMStore_b
T−B.QSP ECS_MAIN.L_BRK1.bQSP_b
T−B.NOut ECS_MAIN.BRK_bNegOut_b
T−B.Out ECS_MAIN.L_BRK1.bOut_b
T−B.CInh ECS_MAIN.L_BRK1.bCInh_b
T−B.MSt ECS_MAIN.L_BRK1.bMStore_b
SP−RL.QSP ECS_MAIN.L_RLQ1.bQSP_b
SP−RL.Cw ECS_MAIN.L_RLQ1.bCwCCw_b
T−RL.QSP ECS_MAIN.L_RLQ1.bQSP_b
T−RL.Cw ECS_MAIN.L_RLQ1.bCwCCw_b
IN−AnOut1 InNeg_bDigOut1
IN−AnOut2 InNeg_bDigOut2
IN−AnOut3 InNeg_bDigOut3
ON−AnOut1 OutNeg_bDigOut1
ON−AnOut2 OutNeg_bDigOut2
ON−AnOut3 OutNeg_bDigOut3
AIF1−1.0 AIF1_bInWord1B0_b
AIF1−1.1 AIF1_bInWord1B1_b
AIF1−1.2 AIF1_bInWord1B2_b
AIF1−1.3 AIF1_bInWord1B3_b
AIF1−1.4 AIF1_bInWord1B4_b
AIF1−1.5 AIF1_bInWord1B5_b
AIF1−1.6 AIF1_bInWord1B6_b
AIF1−1.7 AIF1_bInWord1B7_b
AIF1−1.8 AIF1_bInWord1B8_b
AIF1−1.9 AIF1_bInWord1B9_b
AIF1−1.10 AIF1_bInWord1B10_b
AIF1−1.11 AIF1_bInWord1B11_b
AIF1−1.12 AIF1_bInWord1B12_b
l
Anhang 13
443
