DOEPFER SYSTEM A - 100 Bedienungsanleitung Seite 327

Synthesizer Voice A-111-5
1 2
Fig. 2c: Frontpanel (Inputs and Outputs)
1 VCO Frequency Control Input (1V/Octave)
2 VCO Pulsewidth Control Input
3 VCF Frequency Control Input (1V/Octave)
4 VCA Amplification Control Input
5 ADSR Gate Input
6 VCF External Audio Input
7 Inverted LFO1 Output
8 ADSR Output
9 Audio Output
8
System A-100
3 4 5 6
DOEPFER DOEPFER
DOEPFER DOEPFER
7 8 9
