Accessories
Designation
Flow housing with clamping ring attachment, 1.4404 - version 1
Housing with 1 connection system, DN 40 da 41 x 1.5 (AD x S)
Housing with 1 connection system, DN 50 da 53 x 1.5 (AD x S)
Flow housing with clamping ring attachment, 1.4404 - version 2
Housing with 2 connection systems, DN 65 da 70 x 2 (AD x S)
Housing with 2 connection systems, DN 80 da 85 x 2 (AD x S)
Housing with 2 connection systems, DN 100 da 104 x 2 (AD x S)
Weld-on ring, 1.4404
For installation of the LMIT 09 / S209 transducer in pipes > DN 100
For installation of the LMIT 09 / S209 transducer in container walls
Sealing ring, EPDM
Sealing cover, 1.4404
Clamping ring set, 1.4404
Flow housing with flange connection, 1.4404
Housing with two connection systems; one side for connection of the LMIT 09 / S209 transducer, the other
side with a detachable dummy flange
DN 40 da 41 x 1.5 (AD x S)
DN 50 da 53 x 1.5 (AD x S)
DN 65 da 70 x 2 (AD x S)
DN 80 da 85 x 2 (AD x S)
DN 100 da 104 x 2 (AD x S)
Weld-on flange as in-tank fitting, 1.4404
For installation of the LMIT 09 / S209 transducer in container walls
Moulded seal, EPDM
Dummy flange, 1.4404
Conductivity simulator
(200 µS/cm; 2 mS/cm; 20 mS/cm; 200 mS/cm; 2 S/cm)
(200 µS/cm)
Spare parts list / accessories
109
Art. no. EBS No.
415501223 10001735
415501224 10001270
415501220 10000816
415501221 10001406
415501222 10015966
415501234 10017420
289033 10015888
417001502 10015921
415501232 10001628
415501231 10003210
415501261 on request
415501262 on request
415501263 10015956
415501264 on request
415501265 10015955
415501253 on request
415501251 on request
415501252 on request
289190 10001656
289191 10092914
417101561 Rev. 4-06.2021
