Unit block
Index Name
8 SOFTWARE_REVISION
9 HARDWARE_REVISION
11 DEVICE_ID
12 DEVICE_SER_NUM
33 CIP_SELECT
34 LANGUAGE
35 REF_TEMP
36 CIP1_TEMP_COEFF
37 CIP1_PROD_NO
38 CIP1_RANGE_SEL
39 CIP1_SEN_TYPE
40 CIP2_TEMP_COEFF
41 CIP2_PROD_NO
42 CIP2_RANGE_SEL
43 CIP2_SEN_TYPE
44 CIP3_TEMP_COEFF
45 CIP3_PROD_NO
46 CIP3_RANGE_SEL
47 CIP3_SEN_TYPE
48 CIP4_TEMP_COEFF
49 CIP4_PROD_NO
50 CIP4_RANGE_SEL
51 CIP4_SEN_TYPE
*ac_r = acyclic read; ac_w = acyclic write
SOFTWARE_REVISION: Software revision version.
HARDWARE_REVISION: Hardware revision version.
DEVICE_MAN_ID: Manufacturer-specific device ID.
DEVICE_SER_NUM: Device number from basic settings.
CIP_SELECT: Control configuration of CIP ranges.
Coding Meaning
0 Configuration of CIP range 1
1 Configuration of CIP range 2
2 Configuration of CIP range 3
3 Configuration of CIP range 4
128 Apply the configuration
Byte
Data type s Access Value range
VisibleString 3 ac_r
VisibleString 11 ac_r
VisibleString 12 ac_r
VisbleString 6 ac_r
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
FLOAT ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
UINT8 ac_r,ac_w
Cyclical values of this range are frozen.
Configuration parameters of this CIP range
can be written.
29
Object definitions
Initial value
"2.3"
"3.892.56-01"
"LMIT09 DP/V1"
"000000"
128
0
0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
