Technical Data

Variables and units used
Symbol Physical variables
Electric conductivity
χ
G Electric conductance
R Electric resistance
I Electrical current
U Electrical voltage
Tca Temperature coefficient
J
Absolute temperature
T Thermodynamic temperature
NOTICE!
Absolute temperatures are indicated in units of °C, but it is normal to use K
(Kelvin) for temperature coefficients.
Transmitter housing (deep-drawn stainless steel enclosure)
Data
Dimension, (L x W x H)
Approx. weight
Degree of protection (according to DIN 40050)
Housing feedthroughs, three screwed fittings
(one sealing insert each for 4-6.5/5.5-9/6.5-10 mm)
Transducer connection (only for versions with a
separate measuring cell)
Transducer (material: PEEK)
n Chemical resistance, resistant to inorganic acids and alkalis
Data
Design, cylindrical calotte with measuring channel
diameter
Dimensions (D x H)
Pressure resistance, PN=at 20 °C (see diagram)
Temperature resistance (short term)
Temperature resistance (approx. 30 min)
Temperature sensor, DIN in protective tube (1.4404)
Sealing element, O-ring , art. no. 417001502
(EBS no. 10015921) for clamping ring attachment
(VARIVENT)
Moulded seal, EPDM, art. no. 415501251 for flange
connection
160 x 130 x 75 mm
Up to max. 130 °C
Up to max. 140 °C
101
Technical Data
Unit Meaning
S/cm Siemens/cm
S Siemens
W
Ohm
A Amp
V Volt
% / K % / Kelvin
°C Celsius
K Kelvin
Value Unit
3 kg
67 IP
13,5 PG
13,5 PG
Value Unit
10 mm
55 x 53 mm
16 bar
100 Pt
62 x 3 EPDM
