3.10 Mechanical cleaning/disinfection

Note
The cleaning and disinfection device must be of tested and approved effec-
tiveness (e.g. FDA approval or CE mark according to DIN EN ISO 15883).
Note
The cleaning and disinfection device used for processing must be serviced
and checked at regular intervals.

3.10.1 Mechanical alkaline cleaning and thermal disinfecting

Machine type: single-chamber cleaning/disinfection device without ultrasound
Phase Step
I Pre-rinse
II Cleaning
III Intermediate rinse
IV Thermal disinfection
V Drying
DW: Drinking water
FD–W: Fully desalinated water (demineralized, low microbiological contamination: drinking water quality at least)
*Recommended: BBraun Helimatic Cleaner alkaline
►
Check visible surfaces for residues after mechanical cleaning/disinfect-
ing.
T t Water
[°C/°F] [min] quality
<25/77 3 D–W
55/131 10 FD-W
>10/50 1 FD–W
90/194 5 FD-W
- - -
Chemistry/Note
-
■
Concentrate, alkaline:
– pH = 13
– <5 % anionic surfactant
■
0.5 % working solution
– pH ~ 11*
-
-
According to the program for cleaning and disinfection device
