GEARSHIFT
HUB GEAR
OPERATING THE GEARSHIFT
To shift a gear, you need to turn the shifting rotating grip. Stop pedalling briefly while shifting gears to
permit the gear to shift.
ADJUSTING THE GEAR / INSTALLING AND REMOVING THE REAR WHEEL
DANGER OF ACCIDENT!
• Incorrectly installed wheels may impair braking and cycling performance.
• Tighten all screws and nuts that you loosened again well. Check that the safety
DANGER
washer is placed correctly. The rear wheel may otherwise come loose during the
ride! Perform a careful test ride after installation.
You can find descriptions for setting the different shifting systems and removing/installing the rear
wheel below:
SHIMANO NEXUS INTER 3
SETTING THE GEAR SHIFT
1. Use the turning rotary handle to shift from the 1st to the
2nd gear.
2. Check that the yellow mark
limitation lines
218
3. If the gear shift must be adjusted, release the counter-nut
first .
220
4. Then set the gear shift with the setting screw
5. Tighten the counter-nut
6. Check the correct function of the gear shift by shifting
through the gears several times.
REMOVING THE REAR WHEEL
1. Use the shifting lever to put in the 1st gear.
2. Release the attachment screw
3. Remove the switchbox.
4. Pull the switching pin that you can now see from the axle
is centred within the two
217
.
again well after setting.
220
at the switchbox.
219
.
221
219
GEARSHIFT
217
218
220 221
