STEM WITH ANGLE ADJUSTMENT
DANGER OF DAMAGE AND ACCIDENTS!
• The stem must not be pulled out beyond the mark! The mark of the minimum insertion
depth must not be visible.
DANGER
SETTING THE POSITION AND HEIGHT
1. Loosen the clamp screw
wrench.
2. 2. Adjust the handlebar position or stem height to suit you. Al-
ways observe the mark of the minimum insertion depth
(No warranty if this is not observed!)
3. Tighten the clamp screw
cification (s. chapter Torque specifications).
SET STEM ANGLE
1. Loosen the lateral clamp screw
socket wrench.
2. Now adjust the desired angle at the stem.
3. Then tighten the clamp screw
torque specification (s. chapter Torque specifications).
SETTING THE HANDLEBAR INCLINATION
1. First loosen the clamp block screw of the handlebar
ment with a 4 or 5 mm hexagonal socket wrench.
2. Adjust the inclination angle of the handlebar.
3. Tighten the clamp block screw again well (s. chapter Torque
specifications).
4. Turn the handlebar attachments (e.g. brake lever) back to the
starting position if necessary.
with a 6 mm hexagon socket
46
again according to the torque spe-
48
with a 6 mm hexagonal
45
again according to the
45
.
47 45
attach-
48
HANDLEBAR
44
47
48
