WHEELS • BOTTOM BRACKET CRANK
INSTALLING THE FRONT WHEEL
1. Insert the front wheel straight into the axle holder with the motor
cable on the right (only for models with front-wheel motor).
2. Push the washers and nuts onto the axle.
3. Tighten the axle nuts again with a 18 mm or 15 mm wrench (see
chapter on torque specification).
4. Place both caps onto the axle nuts.
5. Only for models with front hub motor: Plug the motor cable
into the socket
214
6. V-brake rim brake: Connect the brake cable
Hydraulic rim brake: Push the brake cylinder
cantilever socket
7. Hydraulic rim brake: Close the quick-clamping lever
If the lever closes too easily, the quick-clamping screw must be
adjusted (see chapter Brakes).
8. Check that the rim brake works properly. Adjust it if necessary
(s. chapter Brake).
REAR WHEEL
The procedure for removing and installing the rear wheel depends on
the gearshift system installed (see chapter Gearshift).
BOTTOM BRACKET CRANK
DANGER OF DAMAGE AND ACCIDENTS!
• Regularly check that the screw connection of the foot pedal is tight. The pedal
arms may otherwise come loose and the foot pedal, including the inner bearing,
WARNING!
may be damaged.
TIGHTENING THE BOTTOM BRACKET CRANK
1. If present, remove the cover cap on both sides
with a screwdriver.
2. Tighten the screw
mm hexagon socket wrench or a special socket acc. to the
torque specification (s. chapter Torque specifications).
3. Push on the covering cap
EN 60
.
.
210
low depending on model, with an 8
216
again.
215
213
again.
219
back onto the
211
[CLOSE].
212
, e.g.
215
216
210
212
211
213
214
215
