After the turning "green" of signal 211 the functions are carried out such as:
Sequence at start
old new
Pos. 0
1
Pos. 1
2
Pos. 2
3
Pos. 3
4
Pos. 4
Only after this table has been executed, the locomotive will depart!
8.3

Automatic Operation

In the previous chapter switching operation, you have learned that for every recognised vehi-
cle individual changes can be made, in other words, how each vehicle can switch single
points, signals or complete routes all together. On your layout however, there are probably
lots of sequences which are always the same, irrespective of the address of just one
vehicle. For example, in a block system operation, a loco must always come to a halt in front
of a red signal, although it can run through a green signal, no matter what address it has.
Therefore it makes no sense for all vehicles in a block system operation to be given the same
commands all to be programmed individually.
Sequences, which are valid for all vehicles, we call automatic operation. We will now set out
in the following, the various possibilities which the navigation receiver can offer in automatic
operation.

8.3.1 Time controlled, Push-pull, Shuttle Operation

Basic Function
Set up a push-pull, shuttle operation as shown in diagram 10.
Ablauf:
Sequence:
Diagram 10: Time controlled, push-pull, shuttle operation
Functions
f0+f1 (see LNCV 30) are switched on immediately (see LNCV 40)
no electrical accessories programmed for switching
no special functions programmed
5 s of waiting time (see LNCV 5)
have f8 loudspeaker message (see LNCV 31) executed
(see LNCV 41)
have loco-individual (LNCV 110) waiting time of 15 s executed
(LNCV 120)
have f5 train chief's whistle (see LNCV 32) executed (see LNCV 42)
no preset velocity
no further function commands programmed
125
