Command Values for Routes
Besides just being able to switch electrical accessories, the TWIN-CENTER can also switch
the complete routes of points stored in it: 48 routes of points, separated into 3 groups, each
consisting of 16 routes can be programmed within the TWIN-CENTER. These routes within
the TWIN-CENTERs will be switched by the navigation receiver in a very similar way to which
it operates individual accessories. The single command values to switch your routes can
best be seen in the following table:
Command Values to operate the Routes in the TWIN-CENTER
Route 1
1 20010
2 20011
3 20020
4 20021
5 20030
6 20031
7 20040
8 20041
Example:
Route 13 in group 2 will be operated by the command value 20150.
Command Values for Feedback
The TWIN-CENTER recognises so called „feedback-addresses", with which it can visualise
the conditions on your layout, or similarly can be used to control the layout by a computer.
In the s88-Mode, for example, the condition of 8 feed-back locations can be monitored.
The conditions of the feed-backs can also even be changed by the navigation receiver, in
that it can transmit to a feed-back address whether it is in the „free" or „occupied" condi-
tion. There are 1-2048 feed-back addresses, which, if it is for the „free" condition, a figure
„2" is added on as a suffix, and if it is for the „occupied" condition, then a figure „3". This is
very similar to addresses for electrically operated accessories.
Examples:
In order to transmit to the feedback address 1 the „free" condition, then the command value
12 is programmed in. The command value 583 informs the feed-back address 58 „occu-
pied".
Mode for Electrical Accessories and Route Commands
As we have already discovered in the speed and function programming section, an entry in
the LNCV for the mode for electrical and route commands needs to be set in concrete form
to carry out the function commands. The following table shows which mode value cor-
responds to the possible concretising.
120
Route Group
2 3
20090 20170
20091 20171
20100 20180
20101 20181
20110 20190
20111 20191
20120 20200
20121 20201
Route Group
Route 1
9 20050
10 20051
11 20060
12 20061
13 20070
14 20071
15 20080
16 20081
2 3
20130 20210
20131 20211
20140 20220
20141 20221
20150 20230
20151 20231
20160 20240
20161 20241
