13 Adresse
Entry manager
14 Scale factor
15 Module-setting
Part:
value
Teilwert:
A.3

Navigation Receiver LNCV-factory settings

The factory settings of a navigation receiver, which you can access by carrying out a RESET,
which sets LNCV2=99, are as follows:
LNCV Value
0 1
2 2
20 20000
30 1
40 2
21 2000
31 1
41 11
172
Only valid in exit manager, chapter 8.3.5.3.
Here the address of the accompanying entry manager is
entered (factory setting 0). If different to 0, the exit manager
reports to the entry manager to see if a train is waiting to
enter the station. A track for this train will be cleared by the
exit manager. Provided that the data settings LNCV20-119
are both programmed the same for the entry – and exit
manager.
If this CV is different from nil, the sensor will send the
measured loco speed in km/h as a value from 0 to 511 km/h.
The CV contains a scale function for speed measurement
calculated from the distance between sensors and the model
railway scale, chapter 8.4.7
Settable parameter for diverse functions
(factory setting 8),
0 The navigation receiver will be controlled by the
TWIN-CENTER
4 The navigation receiver will be controlled by a LOK-BOSS
0 Operational information will be lost when switching off
8 Operational information will be stored when switching off
Meaning
Module address
Only switching operation with direction recognition
On all vehicles switch
The light
Out, when running from Sensor 1 to Sensor 2
On all vehicles switch
The light
On, when running from Sensor 2 to Sensor 1
