FLEISCHMANN TRAIN-NAVIGATION6893 Handbuch Seite 145

The routes leading to the individual tracks in the station are stored in the TWIN-CENTER. The
last command of each route must unequivocally be to switch the signal before the station,
signal X, to green, so that a waiting train can enter the station.
The LNCVs of the navigation receiver acting as entry manager ahead of the station are pro-
grammed as follows:
LNCV Name
0 Module address
1 2. Sensor addr.
2 Operation style
3 Direction
5 Access.
Waiting time
6 Signal
Block Entry
7 Signal red
Start block
8 Signal green
Intermediate
block
20 Station
track 1
21 Route
to track 1
22 Address/
Category
23 Address/
Category
24 Address/
Category
25 Address/
Category
26 Address/
Category
27 Address/
Category
Value Description
Module address of the navigation receiver
0 Will not be used (double-sensor)
8 Entry manager
Direction which will be active in the navigation
receiver:
0 from Sensor 1 to Sensor 2
1 from Sensor 2 to Sensor 1
0 – 255 Waiting time (seconds) to execute
accessories/routes
X The condition of this signal will be checked by the
navigation receiver. If red = halt, at green = run
through. It need not actually be on the layout but
must be registered in the TWIN-CENTER.
Y0 Signal Y in the now vacant block will be automa-
tically set to red by the navigation receiver. It need
not actually be on the layout but must be registered
in the TWIN-CENTER.
Z1 Signal Z will automatically be set to green by the
navigation receiver so that the train can leave this
section and enter the vacant block. It need not
actually be on the layout but must be registered in
the TWIN-CENTER.
GM Address (LNCV0) of the track manager in station
track 1
Command to switch the route stored in the
TWIN-CENTER leading to track 1 (see chapter 8.2.4)
1. Address or train category, which can enter
track 1
2. Address or train category, which can enter
track 1
3. Address or train category, which can enter
track 1
4. Address or train category, which can enter
track 1
5. Address or train category, which can enter
track 1
6. Address or train category, which can enter
track 1
145
