Reflex Servitec 35 Originalbetriebsanleitung Seite 42

Operation
ER Alarm
Code
10 Maximum pressure
11 Make-up quantity
12 Filling time
13 Filling volume
14 Discharge time
15 Make-up valve
16 Power failure
18 Parameter
Stop ˃ 4 hours
19
20 Maximum make-up
quantity
21 Maintenance
recommended
22 Blow-off time
24 Water treatment
26 Conductivity
measurement
27 Conductivity exceeded
30 I/O module fault
31 EEPROM defective
32 Under voltage
33 Adjustment parameter
35 Digital limit switch
voltage faulty
36 Analogue limit switch
voltage faulty
37 Limit switch voltage
MBV1
43 Outside operating
range
42 — English
Floating
contact
- For "Magcontrol" setting only.
•
Set value exceeded.
- "With water meter" must be activated in the
Customer menu.
•
Set value exceeded.
•
Severe water loss in the system.
- Set value for the maximum filling duration has
been exceeded
- Set value exceeded.
•
- Set value exceeded.
•
"DC" degassing line closed.
•
Dirt trap clogged.
- Contact water meter measures without make-
up request.
- No voltage supply available.
- Setting parameter not entered correctly.
- Device is in stop mode for more than 4 hours.
- Set value exceeded.
- Set value exceeded.
- Blow-off time outside the set value. (Only if
appropriate sensors are used.)
•
- Set value for soft water capacity
exceeded.
•
Time interval for replacement of the
cartridge exceeded.
- Measured value outside the measuring range.
•
- Set value exceeded.
•
Cartridge capacity expired.
•
- I/O module defective.
•
Connection between option card and
controller faulty.
•
Option card defective.
•
Yes EEPROM defective.
•
Internal calculation error.
Yes Supply voltage not achieved.
- EPROM parameter memory defective.
- Short-circuit of limit switch voltage.
- Short-circuit of limit switch voltage.
- Short-circuit of limit switch voltage.
- Operating range exceeded.
Vacuum spray degassing — 01.04.2022-Rev. D
Cause
•
•
•
•
•
•
•
•
•
•
•
Check the make-up valve for leak
tightness.
Connect to voltage supply.
Check setting parameter and correct
if necessary.
Set the controller to Automatic mode.
Reset the "Make-up quantity" meter
in the Customer menu.
Carry out maintenance.
Check set value in the Customer or
Service menu.
•
•
•
•
•
•
•
•
•
Inform Reflex Customer Service.
Check voltage supply.
Inform Reflex Customer Service.
Check the wiring at the digital inputs
(water meter, for example).
Check the wiring at the analogue
inputs (pressure/conductivity).
Check the wiring of the 2-way
motorized ball valve.
•
•
Remedy
Check set value in the
customer or service menu.
Set the actuating pressure of
the safety valve.
Check set value in the
customer or service menu.
Check the water loss and
correct, if necessary.
Check set value in the
customer or service menu.
Check the water loss and
correct, if necessary.
Check set value "Max. Fill
Contact (128)" in the service
menu.
Check the water loss and
correct, if necessary.
Check set value in the
customer or service menu.
Open the degassing line.
Clean the dirt trap.
Replace water treatment
cartridges.
Confirm cartridge replacement
in the customer menu by
pressing the "OK" button twice
in the "Make-up" menu →
"Soft water capacity (032)"
Check set value in the
customer or service menu.
Check the sensor and cabling.
Check set value in the
customer or service menu.
Replace cartridge.
Replace the I/O module.
Check the connection between
option card and controller.
Replace the option card.
Lower the system pressure.
Check ball valves on pump
discharge side.
Alarm reset
-
Quit
Quit
Quit
Quit
Quit
-
-
-
Quit
Quit
Quit
-
-
-
-
-
-
Quit
-
-
-
-
