Parameter Setting
Shut off make-up No
Hardness reduction 8°dH
Maximum make-up 0 Litres
quantity
Soft water capacity 0 Litres
Cartridge replacement 18 months
Desalination (only if "Water treatment" with "Desalination")
Conductivity monitoring No
Shut off make-up No
Hardness reduction 8°dH
Maximum make-up 0 Litres
quantity
Soft water capacity 0 Litres
Cartridge replacement 18 months
Next maintenance 12 months
Volt-free contact Yes
8.2.4 Messages
The display provides alarms in plain text and the ER codes listed below. Use the arrow buttons to scroll through multiple alarms displayed at the same time.
The error memory stores the last 20 alarms for review,  8.2.1 "Customer menu",  40.
Alarm causes can be eliminated by the operator or a specialist workshop. Please contact the Reflex customer service for alarms that cannot be repaired.

Note!
Some messages must be acknowledged with the "Quit" key on the control panel of the controller (see following table), after the cause has been
corrected. All other alarms are automatically reset as soon as the cause has been eliminated.

Note!
Floating contacts, setting in the Customer menu,  8.2.1 "Customer menu",  40.
ER Alarm
Code
01 Minimum pressure
02.1 Low water
02.2 Low water
02.4 Low water
06 Make-up time
07 Make-up cycles
08 Pressure
measurement
Remarks
In the case of soft water
residual capacity = 0
= Target – Actual
Attainable make-up quantity
Attainable water capacity
Replace cartridge
In the case of soft water
residual capacity = 0
= Target – Actual
Attainable make-up quantity
Attainable water capacity
Replace cartridge
Time left to the next due
maintenance
Only the messages marked in
the "Messages" list
Floating
contact
Yes For "Magcontrol" setting only.
•
Set value not reached.
•
Water loss in the system.
•
Pump fault.
•
Expansion vessel defective.
- Dry run protection: Low water switch
•
Defective.
•
Not cabled.
•
Triggered for too long.
- Dry run protection: Low water switch has
actuated too often.
- Vacuum during make-up feed.
•
- Set value exceeded.
•
Water loss in the system.
•
Make-up line not connected.
•
Make-up output insufficient.
- Continuous water loss in the system.
•
- Controller receives incorrect signal.
Vacuum spray degassing — 01.04.2022-Rev. D
Service menu
Parameter
Make-up
Pressure differential,
"NSP" make-up
Pressure differential,
filling pressure PF – P0
Maximum filling duration
Degassing
Idling times between
degassing intervals
Number of degassing
cycles for each interval
Daily start
Next maintenance
Volt-free contact
Cause
•
•
•
•
•
•
•
•
•
•
Open the make-up ball valve.
•
•
•
•
•
•
•
•
Setting Remarks
0.2 bar Only Magcontrol
0.3 bar Only Magcontrol
10 h Only Magcontrol
12 hours Idling times between the
degassing intervals
n = 8 Number of degassing cycles in
one interval
08:00 h Start of the daily degassing
intervals
12 months Time left to the next due
maintenance
YES Only the messages marked in
the message list
Remedy
Check set value in the
customer or service menu.
Check water level.
Check pump.
Check expansion vessel.
Check low water switch.
Open the degassing line.
Clean the dirt trap.
Replace the degassing valve.
Clean the dirt trap.
Replace the degassing valve.
Check set value in the
customer or service menu.
Check water level.
Connect make-up line.
Check set value in the
customer or service menu.
Seal the leakage in the system.
Check/connect the plug
connection at the pressure
transmitter
Check the cable for damage.
Check the pressure sensor.
Operation
Alarm reset
-
Quit
Quit
-
Quit
Quit
Quit
