English – 4
The following settings can be changed via the quick menu:
– <Ride>
All data on the journey so far is reset to zero.
– <eShift> (optional)
The settings vary depending on the gearing in question.
For example, you can set your cadence here, provided
that the gearing supports this function.
Note: Other functions may be available depending on your
eBike equipment.
Start page
If you did not select another page before the last time you
switched off, you will be shown this page.
80%
eMTB
km/h
22.7
State of charge of eBike battery (can be configured)
(a)
(b) Riding mode
(c) Bicycle lights
(h) Unit of speed indicator
(i) Your performance
(j) Speed
(k) Drive power
The indicators (a) to (c) form the statusbar and are shown
on every page.
The navigation bar briefly indicates which page you are on.
You can access additional pages from the start page. The
statistical data, eBike battery range and average values are
displayed on these pages.
If you are on a different page to the start page when the
eBike is switched off, the most recently displayed page will
appear again when the eBike is switched on.
Press the button or
through the pages.
Briefly press the select button
through all the pages. This is how you access
the status page, for example.
Maintenance and Service
Maintenance and cleaning
Do not clean any of the components with pressurised water.
Keep the display of your on-board computer clean.
Clean your on-board computer using a soft cloth dampened
only with water. Do not use cleaning products of any kind.
0 275 007 3BP | (26.04.2024)
If you use a blind plug for the connection socket of
the Purion 400 on-board computer, regularly check that it is
fitted securely. This ensures that no dirt or water gets in and
damages the on-board computer.
Note: The Purion 400 on-board computer may fog up under
certain temperature and humidity conditions. This is not an
error. Put the eBike in a heated room.
Have your eBike checked by an expert at least once a year
(including mechanical parts, up-to-dateness of system soft-
ware).
In addition, the bicycle dealer may enter the service date
based on the distance travelled and/or on a period of time.
In this case, the on-board computer displays a message
telling you when the service date is due each time it is
(a)
switched on.
(b)
Please have your eBike serviced and repaired by an author-
(c)
ised bicycle dealer.
(h)
Have all repairs performed only by an authorised bike
u
(i)
dealer.
(j)
Note: If you are handing in your eBike to a bicycle dealer for
maintenance, it is recommended that you temporarily deac-
(k)
tivate <Lock & Alarm>.
After-sales service and advice on using products
If you have any questions about the eBike and its compon-
ents, contact an authorised bicycle dealer.
For contact details of authorised bike dealerships, please
visit www.bosch-ebike.com.
Disposal and substances in products
You can find information about substances in products at the
following link:
www.bosch-ebike.com/en/material-compliance.
Do not dispose of eBikes and their components with house-
hold waste.
An in-store return is possible, provided the retailer voluntar-
button to scroll
ily offers a return or is legally obligated to do so. Refer to the
national regulations in this case.
to scroll
Check that your personal data has been deleted from the
device.
Batteries that can be removed from the power tool without
destruction must be removed before disposal itself and sor-
ted for separate battery collection.
Further information on the eBike components
and their functions can be found in the Bosch
eBike Help Center.
The drive unit, on-board computer incl. operat-
ing unit, eBike battery, speed sensor, ac-
cessories and packaging should be disposed of
in an environmentally correct manner.
In accordance with Directive 2012/19/EU
and Directive 2006/66/EC respectively, elec-
tronic devices that are no longer usable and de-
fective/drained batteries must be collected
Bosch eBike Systems
