3. Scope of delivery (Fig. 1 + 1a)
Item Quantity Designation
3 1x Steering rod
3c 2x Cable clip
5 1x Gear selector lever
5 a 1x Rubber grip
6 1x Depth stop
7 1x V-belt protection cover
7 a 2x M5 hex screw with collar
8 1x Depth stop bracket
9 1x Mudguard extension (left)
10 1x Strut
11 1x Blade (left)
11 a 1x Blade extension (left)
11b 1x Blade (right)
11c 1x Blade extension (right)
12 2x Blade guard
18 1x Mudguard extension (right)
25 1x Transport wheel
26 1x Motor hoe unit
27 2x Idler
28 2x Wheel axle
28 a 8x Hexagon bolt M10 x 25 mm
28b 8x M10 spring washer
28c 8x M10 hexagonal nut
29 1x Bolt for depth stop bracket
30 1x Split pin
31 2x Bolt Ø 4 mm x 40 mm
32 2x Split pin
33 5x Bolt Ø 6 mm x 20 mm
34 5x Split pin
35 4x Hexagon bolt M8 x 45 mm
36 4x M8 washer
37
38
39
40
A
B
C
D
E
F
G
Optional accessories may not be included in the scope
of delivery
• Potato harvester
• Plough
• Iron wheel
• Adjustable furrow attachment
4. Proper use
The product is designed for chopping and tilling coarse
soil and for working in fertiliser, peat and compost in
domestic applications.
Do not work on slopes with a gradient of more than
10%.
The machine may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or inju-
ries of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, the assembly instructions
and the operating information in the operating manual.
Persons who operate and maintain the machine must
be familiar with it and must be informed about potential
dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the ma-
chine.
www.scheppach.com
4x M8 hexagonal nut
10x M6 x 16 mm hex screw with
collar
10x M6 hex nut with collar
6x Vibration damper
2x Cable ties
1x Screwdriver
1x Spark plug wrench
1x Allen key, 5 mm
1x SW13/16 open-ended
spanner
1x SW12/14 open-ended
spanner
1x SW8/10 open-ended spanner
1x Operating manual
