1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes and
for increasing the reliability and extending the service
life of the product. In addition to the safety instructions
in this operating manual, you must also observe the
regulations applicable to the operation of the product
in your country. Familiarise yourself with all operating
and safety instructions before using the product. Only
operate the product as described and for the specified
areas of application. Keep the operating manual in a
good place and hand over all documents when passing
the product on to third parties.
2. Device description (Fig. 1 - 14)
1. Clutch lever
2. Handle
3. Steering rod
3a. Handlebar bridge
3b. M8 x 20 mm hexagon screw with collar
3c. Cable clip
4. Clamping grip
5. Gear selector lever
5a. Rubber grip
6. Depth stop
34 | GB
7. Belt cover
7a. M5 hex screw with collar
8. Holder (depth stop)
9. Mudguard extension (left)
10. Strut
11. Blade (left)
11a. Blade extension (left)
11b. Blade (right)
11c. Blade extension (right)
12. Blade guard
13. Throttle
14. On/off switch
15. Fuel valve
16. Choke
17. Gearbox oil filler plug
17a. Gearbox oil drain screw
18. Mudguard extension (right)
19. Exhaust pipe
20. Air filter cover
20a. Wing nut
21. Fuel tank
22. Pull starter
23. Oil filler plug with oil dipstick
24. Oil drain screw
25. Transport wheel
25a. Screw
25b. Pin
25c. Split pin
26. Motor hoe unit
27. Idler
28. Wheel axle
28a. Hexagon bolt M10 x 25 mm
28b. M10 spring washer
28c. M10 hexagonal nut
29. Pin for holder (depth stop)
30. Split pin
31. Bolt Ø 4 mm x 40 mm
32. Split pin
33. Bolt Ø 6 mm x 20 mm
34. Split pin
35. Hexagon bolt M8 x 45 mm
36. M8 washer
37. M8 hexagonal nut
38. M6 x 16 mm hex screw with collar
39. M6 hex nut with collar
40. Vibration damper
