FUSE SPECIFICATION

Location Description
F1 30VAC from transformer for the battery charger and the
5VDC / 12VDC supply
F2 24 VDC from batteries for power supply
F3 24 VAC from transformer for power supply
Cable Location Voltage
J11 24-31VAC
J11 30-39VAC
J12 24-29DC
J1 24-28VDC
J1 24-28VDC
J3 24-28VDC
J3 24-28VDC
J6 24-28VDC
J6 24-28VDC
J4 24-28VDC
J4 24-28VDC
J5 24-28VDC
J5 24-28VDC
J7
24-28VDC
24-28VDC
24-28VDC
J8 Bed Unplugged
25VDC
25VDC
Return To Table of Contents
1-44
CPU/Power Board - QDF75-0440
Positive Lead Negative Lead
Blue
Yellow
Pin 1 - Red Pin 2 - Black
Pin 1 - Black Pin 2 - Brown
Pin 2 - Brown
Pin 1- White Pin 2 - Black
Pin 2 - Black Pin 1 - White
Pin 2 - White Pin 1 - Black
Pin 1 - Black Pin 2 - White
Pin 2 - White Pin 1 - Black
Pin 1 - Black Pin 2 - White
Pin 2 - White Pin 1 - Black
Pin 1 - Black Pin 2 - White
Pin 1 - Black Pin 2 - White
Pin 1 - Black Pin 2 - White
Pin 1 - Black Pin 2 - White
Pin 2 - White Pin 1 - Black
Pin 1 - Black Pin 2 - White
2151-109-006 REV A
Amp
10 Amp - 215008 .P
40 Amp - 142 .6185 .5402
40 Amp - 142 .6185 .5402
Red Stepped down voltage from
transformer for power supply
Orange Stepped down voltage from transformer
for battery charger and power supply
Pin 1 - Blue Foot Actuator Down
Gatch Actuator Up
Gatch Actuator Down
Bed Lift-Foot Down
Bed Lift-Head Down
Fowler Actuator Up
Fowler Actuator Down
Brake/Brake Off/Drive Actuator
• Brake
• Brake Off
• Drive
Zoom® Drive Actuator (Model
2152/2154/2156 Only)
Description
Battery/Charger
Foot Actuator Up
Bed Lift-Foot Up
Bed Lift-Head Up
