Zoom DRIVE ACTUATOR REMOVAL AND REPLACEMENT (2152 MODEL ONLY) - (BASE)
®
Tools Required:
• Needle-Nose Pliers
• Pry Bar or 2 x 4
• Diagonal Pliers
Procedure:
1 . Plug bed into wall outlet .
2 . Position the bed height in the middle range .
3 . Remove the center base cover then remove the Zoom® drive actuator cover and set aside .
4 . Using Needle-nose pliers, remove the two rue clips from the clevis pins securing the actuator to the base frame .
5 . Using diagonal pliers, cut the zip ties securing the actuator cable and then unplug the actuator from the quick
connect .
6 . Using a pry bar or a 2 x 4, pry upward on the Zoom® drive actuator frame and push the actuator clevis pins out .
7 . Remove actuator .
8 . Reverse steps to install new actuator .
9 . Test all bed functionality prior to putting bed back into service .
