Quick Reference Replacement Parts List

The parts and accessories listed on this page are all currently available for purchase . Some of the parts identified on
the assembly drawing parts in this manual may not be individually available for purchase . Please call Stryker Customer
Service USA: 1-800-327-0770 for availability and pricing .
Part Name
Electrical Components
Actuator, Brake
Actuator, Foot
Actuator, Fowler
Actuator, Gatch
Actuator, Lift, Foot End
Actuator, Lift, Head End
Angle Sensor, Foot, Fowler, Base, Gatch, Lift
Batteries (Replace both at same time)
Board, CPU/Power
Board, Drive (2152 Zoom® Only)
Board, Headwall
Board, Brake Control
Board, Footboard, Function Section/LEDs
Board, Siderail, Outside (Bed Motion)
Board, Touch Screen, Foot
Fuse, 8Amp Ceramic
Fuse, 10Amp, Main Power
Fuse, 25Amp Cartridge
Load Cell
Motor, Drive (2152 Zoom® Only)
Motor, Drive Actuator (2152 Zoom® Only)
Position Sensor, Brake/Brake Off/Drive
Power Cord
Speaker, Right Siderail
Speaker, Left Siderail
Touch Screen, Footboard
Transformer
Other Components
Caster (2152 Model - all four casters) (2151 Model - both head end casters)
Caster, Steer (2151 Model Only - both foot end casters)
Headboard Assembly
InTouch 3 .0 Footboard Assembly without iBed, without iAudio
InTouch 3 .0 Footboard Assembly with iBed, without iAudio
InTouch 3 .0 Footboard Assembly with iBed, with iAudio
Return To Table of Contents
1-14 2151-109-006 REV A
Part Number
QDF27-1227
QDF27-1216
QDF27-1214
QDF27-1215
QDF27-1251
QDF27-1252
27-2477
QDF9188
QDF75-0440
QDF27-1430
QDF75-0600
QDF27-1097
QDF75-0010
QDF27-1099
QDF2125
QDF2120
QDF8078
QDF2119
QDF27-1372
QDF27-1445
27-2593
QDF27-2024
QDF8066
QDF27-2216
QDF27-2175
QDF27-2193
QDF27-2658
RD27-1970
RD27-1971
27-2583K
27-2760K
27-2761K
27-2762K
