BED LIFT ACTUATOR (FOOT) REMOVAL AND REPLACEMENT - (BASE)

Tools Required:
• Needle-Nose Pliers
• Diagonal Pliers
Procedure:
1 . Plug bed into wall outlet .
2 . Raise head end siderails to full up position and ensure brakes are activated .
3 . Remove head end base cover by pulling up and out .
4 . Remove center base cover by pulling up and out .
5 . Using diagonal pliers, cut the zip tie securing the actuator cable to the base frame .
6 . Using Needle-nose pliers, remove the rue clips from the clevis pins securing the actuator .
CAUTION
Do not remove the clevis pins .
7 . Lower the bed all of the way down so the litter is supported by the base litter stops .
8 . Using the bed up/down controls, tap the up or down button to remove tension on the clevis pins and remove clevis
pins .
9 . Unplug the cable quick connect and remove the actuator .
10 . Reverse the steps to install the new actuator .
11 . Test all bed functionality prior to putting bed back in service .
