CONFIGURATION SCREEN (CONTINUED)
A. Bed Calibration (Continued)
Next
13 . Press the
14 . The "Do Not Touch Bed" screen will appear as
shown in Figure 15 .
15 . When step 3 of the calibration procedure has completed, step 4 of the calibration procedure will begin and
Figure 16 will be displayed as shown below .
Return To Table of Contents
1-22
Maintenance Menu Guide
button when done .
Figure 16: Bed Calibration - Step 4
2151-109-006 REV A
Bed Calibration
Do Not
Touch Bed
Figure 15: Do Not Touch Bed Screen
Cancel
