Problem / Failure
No Electric Brake Motion .
Return To Table of Contents
1-38
Troubleshooting Guide
1 . Verify the Brake Not Set LED is flashing and the Brake Set LED is
OFF .
I . If the Brake Set LED is ON, check manual brake position .
a . If manual brake pedal is in the brake position, the bed
should not move and is okay; go to step 2 .
b . If manual brake is not in the brake position, check the
switch on the patients left side in the middle below the
base hood .
2 . If the brake motor does not run down when the brake button is
pushed, check for 24VDC at connector J7 while pressing the brake
button . Black lead to pin 1, red lead to pin 2 .
2151-109-006 REV A
Recommended Action
