OPTIONAL ZOOM ® DRIVE SYSTEM (MODEL 2152/2154/2156 ONLY)
In addition to the previous warnings and cautions, all of the following warnings and cautions apply to units equipped with
oom
the Z ® .
WARNING
• The 2152/2154/2156 InTouch® Bed is intended for use by trained hospital personnel only . Failure to properly train
personnel could result in injury .
• USE CAUTION while maneuvering the unit with the drive wheel activated . Always ensure there are no obstacles
near the unit while the drive wheel is activated . Injury to the patient, user or bystanders or damage to the frame or
surrounding equipment could occur if the unit collides with an obstacle .
• Use caution when transporting the unit down halls, through doors, in and out of elevators, etc . Damage to the
siderails or other parts of the unit could occur if the unit comes in contact with walls or door frames .
• Put the drive wheel in the neutral position and release the brake before pushing the unit manually . For 2152/2154/2156
models; push the Brake Off button to disengage drive wheel (Zoom
attempt to push the unit manually with the drive wheel engaged . The unit will be difficult to push and injury could
result .
• If unanticipated motion occurs, unplug the power cord from the wall socket, push the battery power on/off switch
to the "OFF" (0) position (the LED will not be illuminated), actuate the drive wheel pedal to the neutral position and
call maintenance .
• In the event the batteries become discharged while using the Zoom
place the drive wheel in Neutral and proceed to push the bed manually . Recharge the batteries prior to using Zoom
again . Continuing to use the Zoom
down position .
• The power save mode is activated after one hour on battery power with no motion release switch activation .
Functions including Bed Exit, Scale and Motion will cease to operate when the unit enters the power save mode .
Injury to the patient could occur if proper patient monitoring protocol is not observed .
• Always unplug the power cord and push the battery power on/off switch to the "OFF" (0) position before service
or cleaning . When working under the frame, always support the litter frame to prevent injury in case the Bed Down
switch is accidently activated .
• Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm . Wash hands after handling .
• Do not modify the InTouch® Model 2152/2154/2156 bed . Modifying the unit can cause unpredictable operation
resulting in injury to the patient or user . Modifying the unit will also void this warranty .
