Note
See "CPU/Power Boards" section for an outline of bed PCB's and voltage test points .
Problem / Failure
No Power to Bed .
(On wall voltage 120VAC)
COUNTRY VOLTAGE (CV) TABLE
VOLTAGE
100V
110V
120V
200V
220V
230V
240V
Return To Table of Contents
1-32

Troubleshooting Guide

1 . Verify the bed is plugged into a functional wall outlet .
A . Check your country voltage option at wall outlet .
I .
II .
2 . Verify the bed main power fuses are good, located in drawer where
power cord plugs into the bed .
FUSE
A . Check for continuity of each 10A fuse .
10A
I .
II .
10A
10A
10A
3 . Verify there is power at the transformer connection (J11) on the
10A
CPU/Power board at the foot end .
A . Check for 24VAC at J11 between the blue and red wires .
10A
I .
10A
II .
III . If 24VDC is not present, check the power cable quick
IV . If (see CV Table) VAC is present, replace the transformer
B . Check for 30VAC at J11 between the yellow and orange wires
for
I .
II .
III . If (see CV Table) VAC is present, replace the transformer
C . Check fuse F1 on the CPU/Power board .
I .
II .
2151-109-006 REV A
Recommended Action
If your country voltage option is present, go to step 2 .
If your country voltage option is not present, contact hospital
maintenance staff and try another outlet .
If each fuse (see CV Table) is good, go to step 3 .
If either fuse (see CV Table) does not have continuity,
replace the fuse .
If 24VAC is present, go to step 4 .
If 24VDC is not present, check the 25 Amp fuse in the fuse
holder on the red wire from the transformer . If bad, replace
the fuse .
connection going to the transformer for (see CV Table) VAC .
If no voltage, follow the cable and repair or replace the
damaged component .
assembly .
the transformer .
If 30VAC is present, go to step 5 .
If 30VAC is not present, check the power cable quick
connection going to the transformer for (see CV Table) VAC .
If no voltage, follow the cable and repair or replace the
damaged component .
assembly .
If fuse is good, replace CPU/Power board .
If fuse does not have continuity, replace the fuse (Littelfuse
215008 .P) .
