CONFIGURATION SCREEN (CONTINUED)
A. Bed Calibration (Continued)
22 . Press the Fowler Up button until the Fowler reaches
the highest height, next press the Gatch Up button
until the Gatch reaches its highest height, lastly
press the Foot Up button until the foot section
reaches its highest height (refer to Figure 21) .
The foot section should be at a flat position .
Next
23 . Press the
24 . The "Do Not Touch Bed" screen will appear as
shown in Figure 22 .
www.stryker.com
Maintenance Menu Guide
button when done .
2151-109-006 REV A
Fowler Up
Figure 21: Head Siderail Control Panel -
(Right Side Shown)
Bed Calibration
Do Not
Touch Bed
Figure 22: Do Not Touch Bed Screen
Return To Table of Contents
Gatch Up
Foot Up
QDF27-2237
Cancel
1-25
