GATCH ACTUATOR REMOVAL AND REPLACEMENT - (LITTER)

Tools Required:
• Needle-Nose Pliers
Procedure:
1 . Plug bed into wall outlet .
2 . Set the brakes using one of the brake control locations or by using the manual brake pedal .
3 . Remove the mattress and set aside .
4 . Raise bed to the full up position .
5 . If the actuator will run, lower the gatch down to take the tension off of the actuator mounting pins . If the actuator
will not run, support the gatch section to take tension off of the actuator mounting pins .
6 . Unplug the actuator cable from the quick connect near the actuator .
7 . Using Needle-nose pliers, remove the two rue clips from the clevis pins holding the actuator in place .
8 . Holding the actuator with one hand, remove the clevis pins securing the actuator to the bed then remove the actuator .
9 . Reverse these steps to reinstall .
Note: If new actuator shaft does not line up with mounting holes, mount the base of
the actuator then plug the actuator in and run it electrically in or out until lined up.
10 . Test all bed functionality prior to putting bed back in service .
