ERROR MESSAGES (CONTINUED)
Touch Screen Error Messages Name
Tilt Error Base
Tilt Error Foot
Tilt Error Gatch
Tilt Error Head
Tilt Error HiLo Foot
Tilt Error Trend
Tilt foot over range
Tilt gatch over range
Tilt head over range
Tilt HiLo foot over range
Tilt Trend over range
Zoom® time out for switch
Return To Table of Contents
1-42
Maintenance Error Messages
Definition
Angle sensor is damaged (Replace sensor) .
Angle sensor is damaged (Replace sensor) .
Angle sensor is damaged (Replace sensor) .
Angle sensor is damaged (Replace sensor) .
Angle sensor is damaged (Replace sensor) .
Angle sensor is damaged (Replace sensor) .
Verify if tilt sensor is still in place . Inspect for a damaged or improperly
assembled tilt sensor or recalibrate bed .
Verify if tilt sensor is still in place . Inspect for a damaged or improperly
assembled tilt sensor or recalibrate bed .
Verify if tilt sensor is still in place . Inspect for a damaged or improperly
assembled tilt sensor or recalibrate bed .
Verify if tilt sensor is still in place . Inspect for a damaged or improperly
assembled tilt sensor or recalibrate bed .
Verify if tilt sensor is still in place . Inspect for a damaged or improperly
assembled tilt sensor or recalibrate bed .
Verify wiring to Zoom® motor .
