CONFIGURATION SCREEN (CONTINUED)
A. Bed Calibration (Continued)
8 .
Raise the bed height to 20 inches measuring
from the top of the seat section to the floor .
Press the Bed Height Up (Head Lift Up)
and Trendelenburg (Foot Lift Up) buttons as
shown in Figure 10 .
9 .
Standing on either side of the bed at the fowler
section, raise the foot siderail and then position
the digital level/inclinometer on the bottom of
the litter below the mattress retainer (refer to
Figure 11) . Using the digital level/inclinometer,
verify the bed is level (0 .0 +/- 0 .2) .
Note: Cycle power on the digital level/
inclinometer prior to placing it on the bottom
of the litter frame and do not zero/calibrate
the digital level/inclinometer.
Next
10 . Press the
"Do Not Touch Bed" screen will appear as
shown in Figure 12 .
Return To Table of Contents
1-20
Maintenance Menu Guide
button when done . The
2151-109-006 REV A
Bed Height Up
(Head Lift Up)
Trendelenburg
(Foot Lift Up)
Figure 10: Head Siderail Control Panel
(Right Side Shown)
Figure 11: Inclinometer placement
Bed Calibration
Do Not
Touch Bed
Figure 12: Do Not Touch Bed Screen
QDF27-2237
Placement
on Litter
Cancel
